Most models are for a 2003 Excalibur. Most are compatible with other year-models, but some aren't. I don't know which, so if it matters you should research it on your own to be sure.

Part: 2003 Excalibur body File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Excalibur 2003 model body. Most of the body is modeled correctly and threaded, however the solenoid screw holes aren't threaded. I'm also not sure on the exact position of the solenoid screw holes either, but they're close. Additionally, the feedneck bore isn't realistic.

Part: Feedneck male specification File type: AutoCAD drawing (.dwg) Created by: AKALMP inc. Description: Specifications for the AKALMP feedneck threading, male component only.

Part: Feedneck female specification File type: SolidWorks library feature part (.sldlfp) Created by: Baldusi Description: Demo model for the female receiving threads.

Part: Bolt piston housing (main) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Bolt piston housing, main section.

Part: Bolt piston housing (endcap) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This subsection screws onto the main part of the bolt piston housing.

Part: Bolt piston internal plate File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This component is located between the two bolt housing sections and is used to hold the internal o-ring in position.

Part: Bolt ram shaft File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Stainless ram shaft for the bolt assembly. The piston head connects at the front, and the bolt pin actuator at the rear. The connection with the actuator isn't threaded in the model.

Part: Bolt piston head File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This brass component is soldered onto the end of the bolt piston ram (front end) and houses the required o-ring seal.

Part: Bolt pin actuator File type: Inventor 10 part file (.ipt) Created by: Ydna Description: "H-block" actuator inside which the bolt pin sits. This part isn't threaded.

Part: Bolt cartridge endcap File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This component screws onto the rear of the Excalibur body to cover the bolt piston pieces (prevents debris from entering) the chamber.

Part: Lightning bolt File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Delrin Lightning bolt for Excal.

Part: Lightning bolt pin File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Bolt pin that connects the bolt with its actuator. This is functinoally correct except it's missing the ball-rounded spring-bearing milling.

Part: Bolt piston retainer screw File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This elongated screw locks the bolt piston in place within the Excalibur body.

Part: Hammer piston housing (main) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Hammer piston housing, main section.

Part: Hammer piston housing (endcap) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This subsection screws onto the main part of the hammer piston housing. The part is modeled backwards so you'll have to flip it ardoun in assembly view.

Part: Hammer piston internal plate File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This component is located between the two hammer piston housing sections and is used to hold the internal o-ring in position.

Part: Hammer ram shaft File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Stainless ram shaft for the hammer assembly. The piston head connects at the rear, and the hammer at the front. The connection with the hammer isn't threaded in the model.

Part: Hammer piston head File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This brass component is soldered onto the end of the hammer piston ram (rear end) and houses the required o-ring seal.

Part: Hammer File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Stainless heavyweight hammer, connected to the front of the hammer ram shaft. This part is also backwards so it'll have to be flipped around.

Part: Tornado valve housing File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Tornado valve housing.

Part: Tornado valve poppet File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Tornado valve poppet, no seal included in the model.

Part: Tornado valve poppet seal File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Tornado valve poppet seal

Part: Tornado valve spring (uncompressed) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This model is for the valve spring's uncompressed shape.

Part: Tornado valve spring (compressed demo) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This model of the valve spring is used when the valve is assembled in position (the valve spring is compressed slightly while idle).

Part: Tornado valve endcap File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Cartridge endcap for the marker's valve section. The valve spring attaches to the stem end of this piece.

Part: Stock LPR housing (main) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Main section of the stock LPR's housing.

Part: Stock LPR housing (endcap) File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Subsection for the stock LPR housing. This piece also houses the reg base seat, but is unthreaded.

Part: Stock LPR base seat File type: Inventor 10 part file (.ipt) Created by: Ydna Description: The regulator's base seat. This is adjusted to control the output pressure. The part is threaded into the LPR housing endcap but no threads are included in the model.

Part: Stock LPR housing internal washer File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This washer is located in the middle of the LPR housing and is held in position by the housing endcap. It's purpose is to hold the piston's internal o-ring in position.

Part: Stock LPR piston File type: Inventor 10 part file (.ipt) Created by: Ydna Description: LPR piston component.

Part: Stock LPR piston base seal demo File type: Inventor 10 part file (.ipt) Created by: Ydna Description: Model for the base seal. I'm not sure of the exact dimensions, making this a demo model.

Part: Stock LPR piston spring File type: Inventor 10 part file (.ipt) Created by: Ydna Description: LPR piston spring in uncompressed form.

Part: Hammer/bolt piston close bumper File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This, larger of the two bumpers, is placed on the externally-visible section of the ram shaft (the bolt and hammer both use one of these).

Part: Hammer/bolt piston open bumper File type: Inventor 10 part file (.ipt) Created by: Ydna Description: This, smaller of the two bumpers, is placed on the inside of the ram shaft, right in front of the piston head (the bolt and hammer both use one of these).
